General
Product Type: Motherboard - micro ATX
Chipset Type: Intel H370
Processor Socket: LGA1200 Socket
Max Processors Qty: 1
Compatible Processors: (supports 10th Generation Intel Core)
Supported RAM
Max Size: 64 GB
Technology: DDR4
Bus Clock: 2133 MHz, 2400 MHz, 2666 MHz, 2800 MHz, 2933 MHz
Supported RAM Integrity Check: Non-ECC, ECC (operate in non-ECC mode)
Registered or Buffered: Unbuffered
Features: Intel Extreme Memory Profiles (XMP) 2.0, dual channel memory architecture, supported ECC modules operate in non-ECC mode
Audio
Type: HD Audio (8-channel)
Audio Codec: Realtek ALC897
Compliant Standards: High Definition Audio
LAN
Network Controller: Realtek RTL8111H
Network Interfaces: Gigabit Ethernet
Expansion / Connectivity
Expansion Slots: 1 x CPU
2 x DIMM 288-pin
1 x PCIe 3.0 x16
1 x PCIe 3.0 x1
1 x M.2 socket (2230 M.2 Key E slot)
1 x Ultra M.2 (2260/2280 M.2 Key M slot)
Storage Interfaces: SATA-600 -connectors: 4 x 7pin Serial ATA
SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2
Interfaces: 2 x USB 2.0
4 x USB 3.2 Gen 1
1 x audio line-in - mini-jack
1 x audio line-out - mini-jack
1 x microphone - mini-jack
1 x PS/2 keyboard / mouse
2 x aerial
1 x VGA
1 x HDMI
1 x DisplayPort
1 x LAN (Gigabit Ethernet)
Internal Interfaces: 1 x audio - header
3 x USB 2.0 - header
4 x USB 3.2 Gen 1 - header
1 x SPI - header
1 x serial - header
1 x speaker - header
Power Connectors: 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type: AMI
BIOS Features: UEFI BIOS, ACPI 6.0 support, SMBIOS 2.7 support
Hardware Monitoring: Chassis fan tachometer, CPU core temperature, fan control, system voltage
Sleep / Wake Up: Wake on LAN (WOL)
Hardware Features: Intel Turbo Boost Max Technology 3.0, 5 Phase Power Design, Premium 50A Power Choke, Sapphire Black PCB, ASRock Auto Driver Installer, ASRock Full Spike Protection, ASRock Live Update, Preboot eXecution Environment (PXE), ASRock EZ Mode, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Instant Flash, ASRock Easy RAID Installer
