Form factor

ATX

Plinth

Intel 1851 (LGA1851)

Chipset

Intel Z890

CPU Compatibility

Core Ultra 200, CPU compatibility list

RAM slots

4x DDR5 DIMM, Dual Channel, UDIMM/CUDIMM, max. 256GB (UDIMM), 256GB (CUDIMM)

RAM Clock Speed OC

max. DDR5-8666

RAM Clock Speed Native

DDR5-5600 UDIMM/DDR5-6400 CUDIMM

ECC Support

no

External connections

1x HDMI 2.1 (iGPU), 1x DisplayPort 1.4 (iGPU), 1x Thunderbolt 4 / USB4 with DisplayPort 2.1 (40Gb/s, PD 15W, iGPU), 1x USB-A 3.1 (10Gb/s), 2x USB-A 3.0 (5Gb/s), 4x USB-A 2.0 (480Mb/s), 1x RJ-45 2.5Gb LAN (Realtek), 3x 3.5mm jack (Realtek ALC897), 2x antenna connector Quick Connect

PCIe slots

1x PCIe 5.0 x16, 3x PCIe 4.0 x16 (2x x4, 1x x1)

M.2 slots

1x M.2/M-Key (PCIe 5.0 x4, 22110/2280), 1x M.2/M-Key (PCIe 4.0 x4, 2280), 1x M.2/M-Key (PCIe 4.0 x4, 22110/2280), 1x M.2/M-Key (PCIe 4.0 x4/SATA, 2280/2260/2242), 1x M.2/E-Key (2230, occupied with WiFi+BT module)

Other interfaces

4x SATA 6Gb/s (Z890)

Internal Connections - USB

1x USB-C 3.1 Key-A header (10Gb/s), 2x USB 3.0 header 20-pin (5Gb/s, 4x USB 3.0), 2x USB 2.0 header 9-pin (480Mb/s, 4x USB 2.0)

Internal connections - other

1x ASUS TB(USB4)_HEADER, 1x serial header, 1x S/PDIF header, 1x TPM header

Internal Connections - Cooling

2x CPU fan 4-pin, 4x fan 4-pin, 1x AIO pump 4-pin

Internal Connections - Power Supply

1x 24-pin ATX, 2x 8-pin EPS12V

Internal connections - lighting

1x 4-pin RGB (+12V/G/R/B, max. 3A), 3x 3-pin ARGB (+5V/DATA/GND, max. 3A, ASUS Gen2)

Buttons/Switches

USB BIOS Flashback (external)

Audio

Realtek ALC897

Graphic

iGPU

Wireless

Wi-Fi 7 (Wi-Fi 802.11a/b/g/n/ac/ax/be, 2x2), Bluetooth 5.4

RAID Level

0/1/5/10

VRM Design

14+1+2+1, 15 virtual CPU phases (2x7+1), 8 real CPU phases (7+1)

MOSFETs VCORE

14x 80A

MOSFETs SOC/VCCGT

1x 80A

MOSFETs VDD_MISC/VCCSA/VCCAUX

2x 80A
