CPU AMD E1-6010 Processor

(Dual core 1.35GHz,10W)

MEMORY Supports Single Channel DDR3 & DDR3L 800/ 1066/ 1333

2 x DDR3 & DDR3L DIMM Memory Slot, Max. Supports up to 16 GB Memory

Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 & DDR3L module

INTEGRATED VIDEO AMD Radeon™ R2 Graphics

Supports HDCP

STORAGE 2 x SATA III Connectors (6Gb/s) : Supports AHCI

* Specifications vary by CPU types

LAN Realtek RTL 8111H

10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

AUDIO CODEC ALC887/ALC897

7.1 Channels, High Definition Audio

USB 2 x USB 3.2 (Gen1) ports (2 on rear I/Os)

6 x USB 2.0 ports (2 on rear I/Os and 4 via internal headers)

EXPANSION SLOT 1 x PCIe 2.0 x16 Slot (x4)

* Specifications vary by CPU types

REAR I/O 1 x PS/2 Mouse

1 x PS/2 Keyboard

2 x USB 3.1 Gen1 Ports

2 x USB 2.0 Port

1 x HDMI Port

1 x VGA Port

1 x LAN Port

3 x Audio Jacks

INTERNAL I/O 2 x SATA III 6.0Gb/s Connectors

2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)

1 x 4-Pin Power Connector

1 x 24-Pin Power Connector

1 x CPU Fan Connector

1 x System Fan Connector

1 x Front Panel Header

1 x Front Audio Header

1 x Clear CMOS Header

1 x COM Port Header

1 x Printer Port Header

1 x S/PDIF out Connector

1 x TPM Header

H/W MONITORING CPU / System Temperature Monitoring

CPU / System Fan Monitoring

Smart / Manual CPU Fan Control

DIMENSION Mini ITX Form Factor Dimension: 17 cm x 17 cm ( W x L )

OS SUPPORT Supports Windows 7 /10

※Biostar reserves the right to add or remove support for any OS with or without notice.

BUNDLE SOFTWARE BullGuard

Smart Speed LAN

ACCESSORIES 2 x SATA Cable

1 x I/O Shield

1 x DVD Driver

1 x Quick Guide

FEATURES Supports 100% Solid capacitor

BIO-FLASHER
