CPU SUPPORT Support for 12th / 13th / 14th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel® Pentium processors/ Intel Celeron processors in the LGA1700 package

MEMORY Supports Dual Channel DDR5 - 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 5200(OC)/ 5000(OC)/ 4800

4 x DDR5 DIMM Memory Slot, Max. Supports up to 192 GB Memory

Each DIMM supports non-ECC 8/ 16/ 24/ 32/ 48 GB DDR5 module

Support Intel® Extreme Memory Profile (XMP) memory modules

INTEGRATED VIDEO Supports DX12

Supports HDCP

STORAGE Total supports 3 x M.2 socket and 4x SATA III (6Gb/s) ports

Intel 12th/13th/14th Processors

1 x M.2 (M Key) Socket (M2M_CPU)

Supports M.2 Type 2280 SSD module

Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD

Intel B760 Chipset

1 x M.2 (M Key) Socket (M2M_SB1):

Supports M.2 Type 2280 SSD module

Supports PCIe 4.0 x4 (64Gb/s) - NVMe SSD

1 x M.2 (M Key) Socket (M2_SB2):

Supports M.2 Type 2242/ 2260/ 2280/ 22110 SSD module

Supports PCIe 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD & SATA lll (6Gb/s) SSD

4 x SATA III Connector (6Gb/s): Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology

* When using PCI-E module on M.2 Socket (M2M_SB1), the PCI-E slot (PCIEx16_2) will be disabled.

* Specifications vary by CPU types

LAN Realtek RTL8125B

10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability

AUDIO CODEC ALC1220

7.1 Channels, High Definition Audio, Hi-Fi

USB 2 x USB 3.2 (Gen2) Type-C port (1 on rear I/O and 1 via internal header)

5 x USB 3.2 (Gen2) port (5 on rear I/Os)

2 x USB 3.2 (Gen1) port (2 via internal header)

6 x USB 2.0 port (2 on rear I/Os and 4 via internal header)

EXPANSION SLOT INTEL 12th/13th/14th Processors

1 x PCIe 5.0 x16 Slot (x16 mode)

INTEL B760 Chipset

1 x PCIe 4.0 x16 Slot (x4 mode)

2 x PCIe 3.0 x1 Slot

* Specifications vary by CPU types

REAR I/O 2 x WIFI Antenna Port

1 x HDMI Port (HDMI2.1)

1 x DP Port (DP1.2)

1 x USB 3.2 (Gen2) Type-C Port

5 x USB 3.2 (Gen2) Port

2 x USB 2.0 port

1 x LAN port

3 x Audio Jack

1 x SMART BIOS UPDATE Button

1 x SMART BIOS USB Port

INTERNAL I/O 4 x SATA III Connector (6Gb/s)

1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module and Intel® CNVi

2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)

1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)

1 x USB 3.2 (Gen2) Type C Header.

1 x 4-Pin Power Connector

1 x 8-Pin Power Connector

1 x 24-Pin Power Connector

1 x CPU Fan Connector

1 x CPU water cooling connector (CPU_OPT)

4 x System Fan Connectors

1 x Front Panel Header

1 x Front Audio Header

1 x Internal Stereo Speaker Header

1 x Clear CMOS Header

1 x COM Port Header

1 x TPM Header

1 x Thunderbolt Header

2 x LED Header (5V)

1 x LED Header (12V)

* M.2 (E key) Wi-Fi card is not provided

H/W MONITORING CPU / System Temperature Monitoring

Smart / Manual CPU Fan Control

CPU/DDR Voltage Monitoring

DIMENSION ATX Form Factor Dimension: 30.5 cm x 24.4cm ( W x L )

OS SUPPORT Supports Windows Windows 10(64bit) / Windows 11(64bit)

※Biostar reserves the right to add or remove support for any OS with or without notice.

BUNDLE SOFTWARE BullGuard

ACCESSORIES 4 x SATA Cable

1 x I/O Shield

1 x DVD Driver

1 x User Manual

FEATURES VIVID LED DJ

BIO-FLASHER

A.I FAN

LED ROCK ZONE
