CPU SUPPORT Support Intel Core™ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1155 package

MEMORY Supports Dual Channel DDR3 1066/ 1333/ 1600

2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory

Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module

* DDR3 1600 memory module (depending on CPU)

INTEGRATED VIDEO By CPU model

STORAGE 4 x SATA II (3Gb/s)

* Specifications vary by CPU types

LAN Realtek RTL8111H

10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability

AUDIO CODEC ALC897

7.1 Channels, High Definition Audio

USB 8 x USB 2.0 port (4 on rear I/Os and 4 via internal headers)

EXPANSION SLOT 1 x PCIe 2.0 x1

1 x PCIe 3.0 x16 Slot (x16 mode, depending on CPU)

* Specifications vary by CPU types

REAR I/O 1 x PS/2 Keyboard / Mouse

1 x VGA Port

1 x HDMI Port

4 x USB 2.0 Ports

1 x LAN port

3 x Audio Jack

INTERNAL I/O 4 x SATA II (3Gb/s)

2 x USB 2.0 Headers (each header supports 2 USB 2.0 ports)

1 x 4-Pin Power Connector

1 x 24-Pin Power Connector

1 x CPU Fan Connector

1 x System Fan Connector

1 x Front Panel Header

1 x Front Audio Header

1 x Internal Stereo Speaker Header

1 x Clear CMOS Header

1 x COM Port Header

H/W MONITORING CPU / System Temperature Monitoring

CPU / System Fan Monitoring

Smart / Manual CPU Fan Control

System Voltage Monitoring

DIMENSION Micro ATX Form Factor Dimension: 17cm x 19.1cm ( W x L )

OS SUPPORT Supports Windows 7/ 8/ 8.1/ 10

※Biostar reserves the right to add or remove support for any OS with or without notice.

BUNDLE SOFTWARE BIO-Remote2

ACCESSORIES 2 x SATA Cable

1 x I/O Shield

1 x DVD Driver

1 x Quick Guide

FEATURES BIO-FLASHER

Supports Charger Booster
