CPU SUPPORT Socket AM5 support AMD Ryzen™ 9000 / 8000 / 7000 series Processors
Support for future AMD Ryzen processors with BIOS update
MEMORY AMD Ryzen 9000 / 8000 / 7000 Series Processors:
Supports Dual Channel DDR5 - 8000+(OC) MT/s, Non-ECC, Un-buffered Memory
4 x DDR5 DIMM Memory Slot, Max. Supports up to 256 GB Memory
Support Intel® Extreme Memory Profile (XMP) memory modules and AMD EXTended Profiles for Overclocking (EXPO) memory modules
INTEGRATED VIDEO Supports DX12
Supports HDCP
STORAGE Total support 4 x M.2 Socket and 6 x SATA (6Gb/s) ports
AMD Ryzen 9000 / 8000G / 7000 Series Processors
1 x M.2 (Key M) Socket (M2M_CPU):
Supports M.2 Type 2280 SSD module
Supports PCIe 5.0 x4 (128Gb/s)/ 4.0 x4 (64Gb/s) - NVMe SSD
AMD X870 Chipset
1 x M.2 (Key M) Socket (M2M_SB_1):
Support M.2 Type 2260/2280/22110 SSD module
Support PCIe 4.0 x 4 (64Gb/s) - NVMe SSD
1 x M.2 (Key M2) Socket (M2M_SB_2):
Support M.2 Type 2260/2280 SSD module
Support PCIe 4.0 x 4 (64Gb/s) - NVMe SSD
1 x M.2 (Key M2) Socket (M2M_SB_3):
Support M.2 Type 2280 SSD module
Support PCIe 4.0 x 4 (64Gb/s) - NVMe SSD
6 x SATA III Connector (6Gb/s):
Supports AHCI & RAID 0, 1, 10
* When using module on M.2 Socket (M2M_SB_3), the PCI-E slot (PCIEX16_3) will be disabled.
* Specifications vary by CPU types
LAN Realtek RTL8125D
10/ 100/ 1000/ 2500 Mb/s auto negotiation, Half / Full duplex capability
AUDIO CODEC Realtek ALC1220-VB2
7.1 Channels, High Definition Audio, Hi-Fi (Front)
USB 2 x USB 4.0/Thunderbolt Type-C Port with (DP)
(2 on rear I/O)
1 x USB 3.2 (Gen2x2) Type-C port
(1 via internal headers)
10 x USB 3.2 (Gen2) port
(8 on rear I/O and 2 via internal header)
4 x USB 2.0 port
(4 via internal headers)
EXPANSION SLOT AMD Ryzen 9000/ 7000 Series Processors
1 x PCIe 5.0 x16 Slot (x16 or x8/x8 mode)
1 x PCIe 5.0 x16 Slot (x8 mode)
* When you use both, PCIEX16_1 and PCIEX16_2 will run x8 mode.
AMD Ryzen 8700G & 8600G (Phoenix1) Processors
1 x PCIe 4.0 x16 Slot (x8 mode)
1 x PCIe 4.0 x16 Slot (disable)
* Only support PCIEX16_1 for x8 mode, PCIEX16_2 will be disable.
AMD Ryzen 8500G & 8300G (Phoenix2) Processors
1 x PCIe 4.0 x16 Slot (x4 mode)
1 x PCIe 4.0 x16 Slot (disable)
* Only support PCIEX16_1 for x4 mode, PCIEX16_2 will be disable.
AMD X870E Chipset
1 x PCIe 4.0 x16 Slot (x4 mode)
* Specifications vary by CPU types
REAR I/O 2 x WiFi Antenna Ports
1 x HDMI Port (HDMI2.1 FRL 2.1 FRL mode)
1 x DP Port (DP1.4)
2 x USB 4.0/Thunderbolt Type-C Port with (DP)
8 x USB 3.2 (Gen2) Ports
1 x 2.5 Gigabit LAN port
5 x Audio Jack
1 x S/PDIF_Out
1 x SMART BIOS UPDATE Button
1 x SMART BIOS USB Port
INTERNAL I/O 6 x SATA III Connector (6Gb/s)
1 x M.2 (E Key) Socket : Supports 2230 type Wi-Fi & Bluetooth module
1 x USB 3.2 (Gen2x2) Type-C Port
(each header supports 1 USB 3.2 (Gen2x2) Type-C port)
1 x USB 3.2 (Gen2) Header
(each header supports 2 USB 3.2 (Gen2) ports)
2 x USB 2.0 Header
(each header supports 2 USB 2.0 ports)
2 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x CPU water cooling connector (CPU_OPT)
4 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Internal Stereo Speaker Header
1 x Clear CMOS Switch Button
1 x Power Switch Button
1 x Reset Switch Button
1 x COM Port Header
1 x TPM Header
1 x Thunderbolt Header
4 x LED Header (5V)
1 x LED Header (12V)
1 x IO LED Header
* M.2 (E Key) Wi-Fi card is not provided
RAID Supports RAID 0, 1 , 10 for M.2 NVMe storage devices
H/W MONITORING CPU / System Temperature Monitoring
Smart / Manual CPU Fan Control
CPU/DDR Voltage Monitoring
DIMENSION ATX Form Factor Dimension: 24.4 cm x 30.5 cm ( W x L )
OS SUPPORT Supports Windows 10(64bit) / Windows 11(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice.
BUNDLE SOFTWARE BullGuard
ACCESSORIES 4 x SATA Cable
1 x Quick Guide
1 x Smart Connector
