Specifications
3.5"/2.5" drive mounts
0 total, 0 included
Dedicated 2.5" drive mounts
4 total, 4 included (2 on motherboard wall)
5.25” drive mounts
0 total, 0 included
Expansion slots
3
Motherboard compatibility
ITX
Power supply type
SFX / SFX-L
Front interface
1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.0, Audio
Total fan mounts
4 x 120 or 2 x 120 and 2 x 140 mm (2x120 mm Aspect PWM fans included)
Top fan
2 x 120 mm or 2 x 140
Bottom fan
2 x 120 mm
Dust filters
Bottom
Top radiator
Up to 315 x 140 mm with total thickness ≤ 52 mm
Up to 300 x 140 mm with total thickness ≤ 58 mm
GPU max length
326 mm
GPU max Height
137 mm
GPU max thickness
48-63 mm (depending on motherboard wall position)
CPU cooler max height
55-70 mm (depending on motherboard wall position)
Cable routing grommets
No
Fixed velcro straps
Yes (2 included)
Captive thumbscrews
PCI-e Blanks
Panels
Aluminum
SFF-Ready Enthusiast GeForce Cards
Yes
*Note
If you wish to use the Era 2 PCIe 4.0 riser cable together with a PCIe 5.0 compatible motherboard and graphics card, make sure you first set the PCIe Slot Configuration in your motherboard BIOS or UEFI to PCIe Gen4 for best system stability.
Other
Case dimensions (LxWxH)
366 x 165 x 314 mm
Case dimensions w/o feet/protrusions/screws
365 x 165 x 314 mm
Net weight
