Form Factor Chassis: 117 * 112 * 49.2 mm

CPU AMD Ryzen™ 7430U

AMD FP6 TDP Barcelo U series 20W

Video Engine Processor AMD Radeon™ Graphics

Memory Dual channel DDR4 260PIN 3200MHz SODIMM, up to 64GB

Audio HDA CODEC

Support DMICS array

Storage 1 x SSD (NVMe x4 Gen 3/SATA), 512G

1 x 2.5" SATA HDD (Tall Chasis)

I/O Port 1 x rear USB 3.2 Gen 2 Type-A, 1 x rear USB 2.0 Type-A

1 x front USB 3.2 Gen 2 Type-A support Power Delivery, 1 x front USB 3.2 Gen 2 Type-A

2 x USB 3.2 Gen 2 Type-C support Power Delivery (back panel)

1 x USB 3.0 Type-C (Data only)

1 x 3.5mm front stereo headset jack

1 x RJ45 (back panel)

2 x HDMI 2.0 (back panel)

1 x DC in (back panel)

1 x CIR

1 x Power Button

1 x Kensington Lock

1 x SD Card

1 x Fingerprint, top side (HW design reserve)

Internal Connector 1 x M.2 key-M slot for PCIe x4 Gen 3 NVMe/SATA SSD

1 x M.2 key-B slot (SATA)

1 x M.2 key 2242 slot

1 x M.2 2230 for WIFI PCIe card only

1 x FAN

Wireless Charging power (option)

2 x USB 2.0

1 x 5.5mm x 2.5mm barrel plug power connector

1 x Front Panel Header 2*6 pin

1 x 16-pin FPC SATA connector to connect an FFC SATA cable to a 7mm 2.5" SATA

LED 2 x POWER LED (Power On: White)

1 x Multi LED (M.2 R/W: White, SATA R/W: White, Bluetooth: White)

Ethernet 10/100/1000/2500 Mbps RJ45

Wireless LAN M.2 Wi-Fi 6 AW-XB547NF, Blutetooth 5.2, 22mm*30mm*2.25mm or

M.2 Wi-Fi 6 AW-XB468NF, Blutetooth 5.2, 22mm*30mm*2.25mm

Kensington Lock Yes

DTPM2.0 Support DTPM 2.0

Battery RTC coin battery

Adapter 19V power supply adapter (65W for Barcelo U) with geo-specific AC cord (IEC C5)

PCBA Dimension 105.75*102.9*1.6mm

Certification CE, FCC, CB, CCC, SRRC, RoHS, PSE, TELEC, CEC

Operating system Microsoft Windows*11(64-bit) support Modern Standby

Accessory VESA Mount (option)
