Form Factor 117 x 112 x 34.2 mm

CPU Intel Alder Lake N150 (6M Cache, up to 3.60 GHz)

TDP 6W

Video Engine Processor Intel UHD Graphics 12th

Memory One channel DDR5 SODIMM, 4800MT/s, up to 16GB

Audio HDA CODEC

Storage 1 x SSD (2280 M.2 SATA & PCIE Gen 3*4), 512G, up to 1TB

I/O Port 1 x USB 3.2 Gen 2 x 1 port(front panel) and 2 x USB 3.2 Gen 2 port(back panel)

1 x TYPE-C with DP 1.4 Alt Mode(back panel) and 1 x TYPE-C Data Only(front panel）

1 x SD card reader

1 x 3.5 mm headphone jack (front panel, support Apple HeadPhone)

1 x RJ45(back panel)

1 x HDMI 2.0(back panel)

1 x Mini DP 1.4(back panel)

1 x DC in(back panel)

1 x PowerButton

1 x Kensington Lock

Internal Connector 1 x M.2 key-M slot(PCIe/SATA)

1 x FAN

1 x RTC

1 x USB2

LED 1 x POWER LED(Power On: Blue, S3: Flashing Orange)

1 x SATA SSD:Red PCIE SSD:Green

Ethernet Intel® 10/100/1000 Mbps Ethernet

LED 10-100M: Flashing Orange, Green, 1000M: Flashing Orange, Green No light

Wireless LAN onboard WiFi6, BT5.2 AW-XM548NF

Kensington Lock Yes

Battery RTC coin battery

Adapter Automatics Voltage adjustment between 100 and 240V AC, 50/60Hz, 45Watts(19V/2.36A), 3Pin, 1.8 meters long & 65W(19V/3.42A)

PCBA Dimension 109.1 x 107.63 mm

Certification CE, RoHS, FCC, CEC, CB, PSE, TELEC

Operating system Windows 11 21H2, PRO

Accessory VESA Mount
