Technical Information

Number of Screens

1

Screen Size Class

27"

Viewable Screen Size

27"

Screen Mode

4K UHD

Panel Technology

In-plane Switching (IPS) Black Technology

Response Time

5 ms

Response Time Details

5ms GTG (Fast)

8ms GTG

Aspect Ratio

16:9

Pixel Pitch

0.1554 mm x 0.1554 mm

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

Panel Mount

Backlight Technology

LED Edgelight System

HDCP Supported

Yes

Maximum Adjustable Height

5.91"

Tilt Angle

-5° to 21°

Swivel Angle

-45° to 45°

Pivot Angle

-90° to 90°

Features

VESA DisplayHDR 600

sRGB

Eye Comfort Technology

Low reflectance with anti-glare and hard-coating 3H

Picture by Picture

Picture in Picture

Color Calibration

Ambient Light Sensor

Cable Lock Slot

Security Lock

BFR Free

PVC Free

Arsenic-free Glass

Mercury-free

Narrow Bezel

Horizontal Frequency

30 kHz to 275 kHz

Vertical Frequency

48 Hz to 120 Hz

Adjustable Stand

Yes

Stand Adjustments

Tilt

Pivot

Height

Swivel

Stand Included

Yes

Glass Hardness

3H

Soundbar Compatibility

Optional soundbar (sold separately)

Video

Maximum Resolution

3840 x 2160

Standard Refresh Rate

120 Hz

Color Supported

1.07 Billion Colors

Native Contrast Ratio

3,000:1

Brightness

450 cd/m2

600 cd/m2

Color Gamut

DCI-P3 99% (CIE1976) (typical)

Display P3 99%

sRGB 100% (CIE1931) (typical)

BT.709 100%

Delta E <1.5 (Average)

Pixel Per Inch (PPI)

163

Interfaces/Ports

Connectivity

1 DisplayPort 1.4 port with DSC support (DRR for Microsoft Windows)

1 DisplayPort 1.4 port out

1 HDMI port (Supports up to UHD 3840 x 2160 120Hz FRL, VRR as per specified in HDMI2.1)

1 Thunderbolt 4 upstream port (DP1.4 (HDCP 2.2) with DSC support, PD: Up to 140W EPR , 2/4 Lanes switching)

1 Thunderbolt 4 downstream port (Downstream, Daisy Chain, 15 W)

1 USB-C (USB 10Gbps KVM) upstream port

1 Analog 2.0 audio line out port (3.5 mm jack)

4 USB Type-A ports 10Gbps

1 RJ45 Ethernet port, 2.5GbE

Quick Access port:

1 USB Type-A 10Gbps port with BC 1.2

2 USB-C 10Gbps downstream ports

USB Type-C (Power Delivery)

Up to 140W EPR

Audio Line Out

Yes

Built-in Devices

Built-in Devices

Ambient Light Sensor

Environmental Conditions

Operating Temperature Range

32°F (0°C) to 104°F (40°C)

Non-operating Temperature Range

-4°F (-20°C) to 140°F (60°C)

Operating Humidity Range

10% to 80% (Non-condensing)

Non-operating Humidity Range

5% to 90% (Non-condensing)

Maximum Operating Altitude

16400 ft

Maximum Non-operating Altitude

40000 ft

Power Description

Input Voltage Range

100V AC to 240V AC

Operating Power Consumption

25.40 W

Standby Power Consumption

0.5 W

Off-Mode Power Consumption

0.3 W

Frequency

60 Hz

50 Hz

Maximum Power Consumption

325 W

Voltage Current

4 Ah

Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

100 x 100

Height

13.92"

Width

24.11"

Depth

2.19"

Height with Stand

21.09"

Width with Stand

24.11"

Depth with Stand

7.44"

Compressed Height with Stand

15.18"

Extended Height with Stand

21.09"

Weight (Approximate)

11.51 lb

Weight with Stand (Approximate)

15.56 lb
