Technical Information

Number of Screens

1

Screen Size Class

27"

Viewable Screen Size

27"

Screen Mode

4K UHD

Panel Technology

In-plane Switching (IPS) Technology

Response Time

4 ms

Response Time Details

4ms GTG (Extreme Mode)

5ms GTG (Fast)

8ms GTG

Aspect Ratio

16:9

Pixel Pitch

0.1554 mm x 0.1554 mm

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

Panel Mount

Backlight Technology

LED Edgelight System

HDCP Supported

Yes

Maximum Adjustable Height

5.12"

Tilt Angle

-5° to 21°

Swivel Angle

-30° to 30°

Pivot Angle

+/-90°

Features

Narrow Bezel

Mercury-free

Arsenic-free Glass

PVC Free

BFR Free

Stand Lock

Cable Lock Slot

Security Lock

Anti-glare

Eye Comfort Technology

Horizontal Frequency

27 kHz to 270 kHz - HDMI 2.1

27 kHz to 270 kHz - DisplayPort 1.4

Vertical Frequency

48 Hz to 120 Hz - HDMI 2.1

48 Hz to 120 Hz - DisplayPort 1.4

Adjustable Stand

Yes

Stand Adjustments

Tilt

Pivot

Height

Swivel

Stand Included

Yes

Glass Hardness

3H

Video

Maximum Resolution

3840 x 2160

Standard Refresh Rate

120 Hz

Color Supported

1.07 Billion Colors

Native Contrast Ratio

1500:1

Brightness

350 cd/m2

Tearing Prevention Technology

AMD FreeSync™ Premium

Color Gamut

99% sRGB (CIE 1931)

Maximum Preset Resolution

3840 x 2160 at 120 Hz

Pixel Per Inch (PPI)

163

Audio

Number of Speakers

2

Speakers

Yes

Interfaces/Ports

Connectivity

Video port

1 USB-C 5Gbps upstream port (DisplayPort 1.4 Alt Mode, Power Delivery up to 65 W)

2 HDMI ports (HDCP 1.4 & 2.3) (Supports up to UHD 3840 x 2160, 120 Hz, FRL, HDR, VRR as per specified in HDMI 2.1)

USB port

1 USB 5Gbps Type-A downstream port with Battery Charging 1.2

1 USB-C 5Gbps downstream port (Power Delivery up to 15 W)

1 USB 5Gbps Type-A downstream port

USB Type-C (Power Delivery)

65 W

Built-in Devices

Built-in Devices

NA

Environmental Conditions

Operating Temperature Range

32°F (0°C) to 104°F (40°C)

Non-operating Temperature Range

-4°F (-20°C) to 140°F (60°C)

Operating Humidity Range

10% to 80% (Non-condensing)

Non-operating Humidity Range

5% to 90% (Non-condensing)

Maximum Operating Altitude

16400 ft

Maximum Non-operating Altitude

40000 ft

Power Description

Input Voltage Range

100V AC to 240V AC

Operating Power Consumption

25.2 W

Standby Power Consumption

0.4 W

Off-Mode Power Consumption

0.3 W

Frequency

50 Hz

60 Hz

Maximum Power Consumption

180 W

Voltage Current

2.30 A

Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

100 x 100

Height

14.02 in.

Width

24.08 in.

Depth

2.36 in.

Height with Stand

20.42 in.

Width with Stand

24.08 in.

Depth with Stand

7.89 in.

Compressed Height with Stand

15.30 in.

Extended Height with Stand

20.42 in.

Bezel Width (Top)

0.29 in.

Bezel Width (Bottom)

0.51 in.

Bezel Width (Left)

0.29 in.

Bezel Width (Right)

0.29 in.

Weight (Approximate)

10.69 lb

Stand Height

16.21 in.

Stand Width

9.76 in.

Stand Depth

7.89 in.

Weight with Stand (Approximate)

14.79 lb
