Technical Information

Number of Screens

1

Screen Size Class

24"

Viewable Screen Size

23.8"

Screen Mode

WQHD

Panel Technology

In-plane Switching (IPS) Technology

Response Time

5 ms

Response Time Details

8ms GTG

5ms GTG (Fast)

Aspect Ratio

16:9

Pixel Pitch

0.2058 mm x 0.2058 mm

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

Panel Mount

Backlight Technology

LED Edgelight System

HDCP Supported

Yes

Maximum Adjustable Height

150 mm

Tilt Angle

-5° to 21°

Swivel Angle

-45° to 45°

Pivot Angle

+/-90°

Features

Narrow Bezel

Mercury-free

Arsenic-free Glass

PVC Free

BFR Free

Stand Lock

Cable Lock Slot

Security Lock

Anti-glare

Eye Comfort Technology

sRGB

Horizontal Frequency

30 kHz to 150 kHz

Vertical Frequency

48 Hz to 100 Hz

Adjustable Stand

Yes

Stand Adjustments

Swivel

Height

Pivot

Tilt

Stand Included

Yes

Glass Hardness

3H

Operation Hours

8 Hours/5 Days

Video

Maximum Resolution

2560 x 1440

Standard Refresh Rate

100 Hz

Color Supported

16.7 Million Colors

Native Contrast Ratio

1,500:1

Brightness

350 cd/m2 (typical)

Color Gamut

99% sRGB (CIE 1931)

Maximum Preset Resolution

2560 x 1440 at 100Hz

Pixel Per Inch (PPI)

123

Interfaces/Ports

Connectivity

Video port

1 HDMI port (HDCP 1.4) (Supports up to QHD 2560 x 1440 100Hz TMDS as per specified in HDMI 2.1)

1 Display Port 1.4 (HDCP1.4)(Support up to 2560 x 1440 100Hz)

1 DisplayPort (out) port with MST (HDCP 1.4)

USB port

1 USB-C 5Gbps upstream port (DisplayPort 1.4 Alternate mode, Power Delivery up to 90W)

1 USB-C 5Gbps downstream port

3 USB 5Gbps Type-A downstream ports

Ethernet port

1 RJ45 Ethernet port, 1GbE

USB Type-C (Power Delivery)

90 W

Built-in Devices

Built-in Devices

NA

Environmental Conditions

Operating Temperature Range

32°F (0°C) to 104°F (40°C)

Non-operating Temperature Range

-4°F (-20°C) to 140°F (60°C)

Operating Humidity Range

10% to 80% (Non-condensing)

Non-operating Humidity Range

5% to 90% (Non-condensing)

Maximum Operating Altitude

16400 ft

Maximum Non-operating Altitude

40000 ft

Power Description

Input Voltage Range

100V AC to 240V AC

Operating Power Consumption

16.5 W

Standby Power Consumption

0.3 W

Off-Mode Power Consumption

0.3 W

Frequency

50 Hz

60 Hz

Maximum Power Consumption

185 W

Voltage Current

2.0 A
