Technical Information

Number of Screens

1

Screen Size Class

32"

Viewable Screen Size

31.5"

Screen Mode

WQHD

Panel Technology

In-plane Switching (IPS) Technology

Response Time

5 ms

Response Time Details

8ms GTG

5ms GTG (Fast)

Aspect Ratio

16:09

Pixel Pitch

0.2727 mm x 0.2727 mm

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Mount Type

Panel Mount

Backlight Technology

LED Edgelight System

HDCP Supported

Yes

Maximum Adjustable Height

5.91"

Tilt Angle

-5° to 21°

Swivel Angle

-30° to 30°

Pivot Angle

+/-90°

Features

BFR Free

PVC Free

Arsenic-free Glass

Mercury-free

Narrow Bezel

Stand Lock

Cable Lock Slot

Security Lock

Anti-glare

Eye Comfort Technology

sRGB

Adjustable Stand

Yes

Stand Adjustments

Swivel

Height

Pivot

Tilt

Stand Included

Yes

Glass Hardness

3H

Operation Hours

8 Hours/5 Days

Video

Maximum Resolution

2560 x 1440

Standard Refresh Rate

100 Hz

Color Supported

1.07 Billion Colors

Native Contrast Ratio

1,500:1

Brightness

350 cd/m2

Color Gamut

99% sRGB (CIE 1931)

Maximum Preset Resolution

2560 x 1440 at 100Hz

Pixel Per Inch (PPI)

93

Interfaces/Ports

Connectivity

Video port

1 HDMI port (HDCP 1.4) (Supports up to QHD 2560 x 1440 100Hz TMDS as per specified in HDMI 2.1)

1 Display Port 1.4 (HDCP1.4)(Support up to 2560 x 1440 100Hz)

1 DisplayPort (out) port with MST (HDCP 1.4)

USB port

1 USB-C 5Gbps upstream port (DisplayPort 1.4 Alternate mode, Power Delivery up to 90W)

1 USB-C 5Gbps downstream port

3 USB 5Gbps Type-A downstream ports

Ethernet

RJ45 Ethernet port, 1GbE

USB Type-C (Power Delivery) upstream port

Up to 90 W

USB Type-C (Power Delivery) downstream port

Up to 15 W

Built-in Devices

Built-in Devices

NA

Environmental Conditions

Operating Temperature Range

32°F (0°C) to 104°F (40°C)

Non-operating Temperature Range

-4°F (-20°C) to 140°F (60°C)

Operating Humidity Range

10% to 80% (Non-condensing)

Non-operating Humidity Range

5% to 90% (Non-condensing)

Maximum Operating Altitude

16400 ft

Maximum Non-operating Altitude

40000 ft

Power Description

Input Voltage Range

100V AC to 240V AC

Operating Power Consumption

23.10 W

Standby Power Consumption

0.4W

Off-Mode Power Consumption

0.3W

Frequency

60 Hz

50 Hz

Maximum Power Consumption

192 W

Voltage Current

2.80 Ah

Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

100 x 100

Height

16.27" (413.15 mm)

Width

28.09"

Depth

1.97"

Height with Stand

24.37"

Width with Stand

28.09"

Depth with Stand

8.46"

Compressed Height with Stand

18.46"

Extended Height with Stand

24.37"

Bezel Width (Top)

0.29"

Bezel Width (Bottom)

0.51"

Bezel Width (Left)

0.30"

Bezel Width (Right)

0.30"

Weight (Approximate)

14.62 lb

Weight with Stand (Approximate)

20.92 lb
